REF AE-01-01

Limpet Coil Reactor

Manufacturer & supplier · Pune, Maharashtra, India

A jacketed reactor with a half-pipe limpet coil welded to the shell for efficient, uniform heating or cooling. Built for refining and extracting liquids in chemical and pharmaceutical plants, using high-grade raw material and modern fabrication in compliance with industry standards.

Key features

Corrosion resistance
Dimensional accuracy
High strength
Durability

Limpet Coil Reactor specifications
Reference	AE-01-01
Category	Process Reactors
Applications	Chemical, Pharmaceutical
Materials	SS 304 / 316 / 310, Duplex, MS, Inconel, Titanium, Monel, Copper, Brass
Testing	Hydraulic (up to 350 bar), pneumatic, leakage, tolerance
Design	In-house CAD/CAM · built to client specification
Delivery	By road, pan-India

Request a quote Call +91 80438 92300

Every unit is custom-engineered. Send capacity, operating pressure/temperature and MOC for an accurate quotation.

01 / Overview

Limpet Coil Reactor manufacturer in Pune

Arsh Engineering manufactures process reactors in Pune for chemical, pharmaceutical, dyestuff and speciality-chemical plants. Our range covers limpet coil reactors, jacketed process reactors, SS reactors and agitated chemical reactors, each built around your batch volume, operating pressure and temperature.

Shells are rolled on our 2500 mm plate-rolling machine, dished ends are formed on a 300-ton hydraulic press, and every reactor is TIG-welded and hydro-tested before dispatch. Choose SS 304, SS 316, SS 310, duplex steel or alloys such as Inconel, titanium and Monel to match your chemistry.

02 / Frequently asked

What materials can the limpet coil reactor be built in?

We fabricate the limpet coil reactor in SS 304, SS 316, SS 310, duplex stainless steel or mild steel, and in Inconel, titanium, Monel, copper or brass on request — chosen to suit your process fluid, pressure and temperature.

Can the limpet coil reactor be customised?

Yes. Every unit is engineered to your process data sheet — capacity, design pressure and temperature, nozzle orientation and material of construction — with GA drawings prepared in-house on CAD for your approval.

How is it tested before dispatch?

Each unit is hydraulically tested on our test set-up (rated to 350 bar), along with pneumatic, leakage and dimensional tolerance checks, before it leaves our Pune works.

Do you supply outside Pune and Maharashtra?

Yes. We deliver by road across India with tailor-made packaging for safe transit.
